Description

Lightweight yet powerful, Yorkville’s new YXL line promises high definition and power in easily manageable formats.
Designed as an all-purpose speaker with the Musician & DJ in mind, each YXL cabinet features 3 channels. The cabinet supports Bluetooth streaming and EQ pushbutton controls for Concert, Club & Monitor modes.
YXL12P Details
Program Power: 500 Watts Program (1000 Watts Peak)
12-inch woofer with 2-inch voice coil
3 Channels plus Master level
1-inch compression driver
90 x 40 degrees HF dispersion
ABS / Polypropelene cabinet construction
Bluetooth streaming
3 performance modes (Concert, Club, Monitor)
YXL12P Specifications
System Type – Active Loudspeaker
Active or Passive – Active
Power Rating (Watts) – 500 Watts Program (1000 Watts Peak)
Max SPL (dB) – 126dB Peak
Frequency Response (Hz +/- 3dB) – 47 – 16k (Hz +/-3dB)
Dispersion (H x V) – 90 x 40
Crossover Frequency (Hz) – 1.6kHz
HF Horn – Integrated into Baffle
LF Driver(s) – 12-inch (2-inch voice coil)
LF Power Rating (Watts) – 450 Watts Program (900 Watts Peak)
HF Power Amplifier (Watts) – 50
HF Amplifier Type – Class A/B
LF Amplifier Type – Class D
Cooling Scheme – Speed controlled fan
Power Cable – Yes
Power Switch – Yes
Inputs – 2 x XLR, 2 x 1/4″, 1/8″, Bluetooth and Main in (XLR)
Level Controls – x3 Channels + Master
EQ Controls – Push button select, Concert, Club, Monitor
Limiter – Multiband excursion, RMS, rail
Other Controls / Features – 100 Hz HP with Sub, Mixer IN/OUT, Stereo/Mono out, 3.5mm Aux in, BT streaming
Feet – Rubber
Bar Handles – 1 x Side / 1 x Back
Flying Hardware – 2 (Top), 1 (Pullback)
Enclosure Materials – Polypropelene, Metal grille
Baffle Material – Polypropylene
Grille – Powder Coated Steel with Grille Cloth
Other Details – Rubber feet on bottom and side with the monitor Wedge
Dimensions (DWH xbackW, inches) – 13.5 x 14 x 23
Dimensions (DWH xbackW, cm) – 34 x 35.5 x 58.5
Weight (lbs/kg) – 38 / 17.24
