Description

OUTPUT A/MONO, B: dBu

– Output Impedance
OUTPUT A/MONO, B: 1 k ohms

– Recommended Load Impedance
OUTPUT A/MONO, B: 10 k ohms or greater

– Bypass
Buffered bypass

– Controls
RHYTHM switch, LOOP switch
VALUE knob, RHYTHM LEVEL knob, LOOP LEVEL knob
MENU button, EXIT button

– Display
16 characters x 2 lines LCD (with backlit)

– Indicator
RHYTHM indicator, LOOP indicator

– Connectors
INPUT (A/MONO, B) jacks, OUTPUT (A/MONO, B) jacks: 1/4-inch phone type
CTL 1, 2/EXP jack: 1/4-inch TRS phone type
MIDI (IN, OUT) jacks: stereo miniature type
DC IN jack
USB COMPUTER port: USB micro B type

– Power Supply
AC adaptor

– Current Draw
250 mA

– Dimensions
101 (W) x 138 (D) x 63 (H) mm
4 (W) x 5-7/16 (D) x 2-1/2 (H) inches
(excluding rubber foot)

101 (W) x 138 (D) x 65 (H) mm
4 (W) x 5-7/16 (D) x 2-9/16 (H) inches
(including rubber foot)

– Weight (excluding AC adaptor)
620 g
1 lbs 6 oz

– Accessories
Owner’s Manual
Leaflet USING THE UNIT SAFELY
AC adaptor
Rubber foot x 4

– Options (sold separately)
Footswitch: FS-5U
Dual footswitch: FS-6, FS-7
Expression pedal: FV-500H, FV-500L, EV-30, Roland EV-5
TRS/MIDI connecting cable: BMIDI-5-35

* 0 dBu = 0.775 Vrms
